International Journal of Trend in Scientific Research and Development (IJTSRD) ISSN: 2456-6470
                                                   nd
                                  Special Issue of 2  International Congress of Engineering
                  . 1 (   645 ) 2  ) 5 . 0 ( * ) 5 . 0 ( *    67 . 65
           n                               67 . 65   68
                        . 0 (  10 ) 2    . 0  01
               
                                     
        The  study  indicated  that  for  the  investigation  of  the
        production process, using 90% of reliability and 10%
        of allowed error, 68 observations or time takings will
        be needed for the investigation.


        Once we know how many observations will be made,
        we took the time it takes each of the 3 processes with
        the 2 pieces (product A and product B) and these were
        the results obtained:

          Milling:  part  A  takes  6.71  minutes  and  part  B     Figure 2. SIMPLEX® PHP main screen
            takes 8.71 minutes
                                                                Then  Figure  3  shows  the  entry  of  the  variables  into
          Production time is 480 minutes.                      the PHP SIMPLEX® program.

          Turning:  part  A  takes  8.71  minutes  and  part  B
            takes  10.71  minutes.  Its  production  time  is  480
            minutes.
          Finishing  finish:  part  A  takes  11.71  minutes  and
            part B takes 13.71 minutes.
          Its production time is 480 minutes.

          Part A is known to earn $ 100 and part B earns $
            125.


        For  the  phase  of  modeling,  and  taking  the  variables
        that lead to the process, the mathematical model was
        then  formulated.  The  mathematical  model  was  as
        follows:

                        : 100 + 125                    Figure 3. Example of input variables in PHP


                       6.71 + 8.71 ≤ 480                                       SIMPLEX®


                      8.71 + 10.71 ≤ 480


                     11.71 + 13.71 ≤ 480                    The program helps to see how the problem is solved


                              ,  ≥  0                       either directly or only the last result. For space saving,


                                                                the last table of the final result is shown in figure 4.
        Where part A will be the variable x1 and part B will
        be x2. The mathematical model remained with two
        variables and three restrictions, due to the processes
        by which the two products pass.
        For the resolution phase of the model, the PHP
        SIMPLEX® tool was used, because it is a free and
        easy-to-use software for solving operations research       Figure 4. Final solution in PHP SIMPLEX®
        problems. Figure 2 shows the main screen and the
        entry of the two variables and three restrictions.      The results of the problem are: Production of piece A
                                                                equal to 0, production for piece B 35.01 products and
                                                                maximum gain is $ 4376.36.
